Solenoid valves are controlled by an electric current through a solenoid coil. The speed controls limit the amount of electricity able to pass through over a period of time.

bray-valve
Manufacturer

Bray

Summit Availablity:  AB, SK

Details

These units can be used with either spring return or double acting actuators where on/off electrical operation is required. Units have 1/2” NPT conduit connections and IP65 DIN units have cable gland PG9 connectors, also available with 1/2” NPT conduit adapters. The coils are UL recognized and CSA certified. All Series 63 solenoids carry the CE mark.

Features:
• Compact
• Modular
• Pilot Operated
• Spool Control Valve
• Convertible From 3-Way (3/2) to 4-Way (5/2)
• Spring Return or Double Acting

Solenoid options:
• Stainless Steel housings
• Low-powered units
• Intrinsically safe units
• BUS solenoids are available for DeviceNet and Profibus-PA protocols
• AS-I Interface solenoids with IP65 DIN/PG9 cable gland connectors are available
• All direct mount to Bray pneumatic actuators.
• Speed controls that allow independent control of speed in both directions

view brochure »

fnw-valve-logo
Manufacturer

FNW Valve Co.

Summit Availablity:  AB, BC, MB, SK

Details

FNW offers solenoid valves that are mountable in any position, and optional flow controls are available.

• Pilot Operated
• Standard Manual Operator
• DIN, Watertight, and Explosionproof Solenoids Available
• Single and Dual Solenoid Constructions
• Mountable in Any Position

8551 Series
• Pilot Operated
• Compact Spool Valve (Convertible from 3/2 to 5/2)
• NAMUR Pad Mount Construction
• Standard Manual Operator
• DIN, Watertight, and Explosionproof Solenoids Available
• Single and Dual Solenoid Constructions

8342 Series
• Direct Acting Operation
• High Flow Construction
• Slide Style Valve
• No Minimum Operating Pressure Differential Required to Shift Valve

8344 Series
• Pilot Operated
• Robust Construction
• Piston-Operated Poppet Design for High Flow
• For Use with Air or Water

8345 Series
• Pilot Operated
• Compact Valve for General Service Applications

view specification sheet »

topworx-logo
Manufacturer

TopWorx

Summit Availability:  AB, BC, MB, SK

Details

D Series
DXP

Explosion Proof/Flameproof , Epoxy-coated Aluminum, Class I Div 1 & 2 / EEx d IIB
D-ESD
Flameproof/Explosion Proof, Aluminum, Class I Div 1 & 2 / EEx d IIB II2G
DXR
Non-Incendive/Intrinsically Safe, Composite Resin, Class I Div 2 / Ex me II2G
DXS
Explosion Proof/Flameproof, 316L Stainless Steel, Class I Div 1 & 2 / EEx d IIB II2G
DVC
Non-Incendive, Direct-mount resin with LEDs, Class I Div 2 / EEx nc IIC II3G

T Series
TXP

Explosion Proof/Flame Proof/Intrinsically Safe, Direct-mount Aluminum, Ex d IIB/IIC II2GD / EEx ia IIC II2GD
TVA
Intrinsically Safe, Direct-mount Resin, EEx ia IIC II2G
TXS
Explosion Proof/Flame Proof/Intrinsically Safe, Direct-mount 316L Stainless Steel, Ex d IIB/IIC II2GD / EEx ia IIC II2GD
